MMCX RF Coaxial Connector Wireless Passive MCX GPS Antenna WIFI Receiver Durable

Product Categories

Shenzhen Yunding Communication Electronics Co.,Ltd

Contact Now

Name: MMCX RF Coaxial Connector Wireless Passive MCX GPS Antenna WIFI Receiver Durable
Brand: Yunding
Price: 0.5 USD

Brand Name : Yunding

Model Number : KJ0051

Certification : ROHS

Place of Origin : GUA , China

MOQ : 20

Price : $0.5-1.0pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 100000pcs a week

Delivery Time : 5-8 work days

Packaging Details : 100 pieces/bag

Gender : Male and Female

Application : antenna

connector : mmcx

Impedance : 50Ω

Material : Copper

Plating : Gold

Product name : Free Sample Wireless Passive MCX GPS Antenna WIFI Receiver

Color : Gold

Vswr : ≤1.5

Contact Now

Free Sample Wireless Passive MCX GPS Antenna WIFI Receiver MMCX Connector

Product Description

Temperature range	-55—+155℃(PE Cable -40—+85℃)
Vibration	98m/S²(10-2000Hz)10g
Impedance	50Ω
Frequency range	DC-12.4GHz(Semi-Rigled Cable DC-18GHz)
Working voltage	335V r.m.s at sea level
Withstanding voltage	1000V r.m.s at sea level
Contact resistance
Center contact	≤3mΩ
Outer contact	≤2.5mΩ
Insulation resistance	≥5000MΩ
Center conductor retention force	≥0.28N
Coupling nut retention force	≥180N
Insertion loss	≤0.15dB/6GHz
Voltage Standing Wave Ratio
Straight	≤1.10+0.02f
	≤1.07+0.018f
Right angle	≤1.20+0.03f
	≤1.17+0.02f
Durability(mating)	≥500times(Cycles)

MMCX RF Coaxial Connector Wireless Passive MCX GPS Antenna WIFI Receiver Durable

Packaging & Shipping

100 pieces/bag

MMCX RF Coaxial Connector Wireless Passive MCX GPS Antenna WIFI Receiver Durable

Our Services

Stock condition is always updating, welcome to contact us for more details.

We promise to only quote products with 100% real condition, never sell refurbished or copy as original.

If products are copy or refurbished, we will make you clear about it and you can make choice by yourself.

Our object is to make long-term cooperation.

Choose us, you will find us professional, always reliable and easy to do business.

Shop here with confidence, we provide you with excellent after-sales service, you will never regret choosing us.
